Quick Details

  • Place of Origin: Jiangsu, China (Mainland)
  • Brand Name: Reliable
  • Model Number: PWS
  • Type: Round Sling
  • Shape: Endless
  • Material: Polyester
  • Lifting Capacity: 1 ton- 24 tons
  • Sling Color: violet, green, yellow, gray, red, brown, blue, orange
  • Lifting Eye Type: Flat Eye
  • Certification: CE,SGS,GS,ISO,EN
  • Product name: Heavy Duty Endless Soft Polyester Round Sling
  • All Parameters: Can be Customized
  • Safety factor: 5:1 6:1 7:1 8:1
  • Standard: EN1492-1:2008+A1
  • Usage: For rigging and lifting applications
  • Outer Sleeve: Double ply outer sleeve
  • Materail: 100% high tenacity industrial polyester yarn
  • Inner core: made of 60000D twisted polyester yarn
  • Sample: Free but the freight

Packaging & Delivery

Packaging Details Shrink Film or Standard Export Carton/container , as required for Heavy Duty Endless Soft Polyester Round Sling
Delivery Time Within 30 days after order confirmed



 Heavy Duty Endless Soft Polyester Round Sling

Specification
Item NamePolyester Endless Round Sling
Material100% High tenacity industial polyeter yarn
Inner Coremade of 60000D twisted polyester yarn
Protection SleeveDouble ply outer sleeve, extremely wear-resistant
Working Load1T-100T
Length from 1m to 20m up,can be customized as required
Safety Factor8:1, 7:1, 6:1, 5:1
Low Elongation<=7%
Standard According to Machinery Directive 2006/42/EC and EN1492-1:2008+A1
CertificatesCE & G.S. certified



Product Description

Technical specifications

  • All products can be customized base on clients requirement
  • Can be single ply or double ply, sawing method is different.
  • The specification can be adjusted according to the customers‘ needs.
  • Loading surface is wide, to reduce the weight at each loading point.
  • No damages to tender objects.
  • Various loading method.
  • High strength/weight ratio.
  • Anti-abrasion and anti-incision protection sleeve can be attached.
  • Has special label, working load is differentiated by colors according to  international standard. Easy to identify even if the sling has been abrased.
  • Light and soft, can be used in samall narrow space.
  • After PU processing, anti-abrasion is enhanced.
  • Non-conductive, no danger of electric stroke.
  • Im compliance with European Standard En1492-1:2000 and Chinese Standard GB/T8521-1997
  • The elongation of sling is not more than ≤ 7%.
  • The working temperature range -40°C—100°C.

Other available standard:

  • Standard: ISO: ISO4878
  • European: EN1492-2: 2000
  • Australian: AS 4497




Max.SWL=Mode Coefficient P*Rated Working Load     Max.SWL of lifting method

Code

Color

Minimum Breaking Load (Kg)

Rated Working Load (Kg)

Upright

P=1 (Kg)

Choked

P=0.8 (Kg)

Angle 45 P=1.8 (Kg)

Angle 90 P=1.4 (Kg)

EB-01

purple

6000

1000

1000

800

1800

1400

EB-02

green

12000

2000

2000

1600

3600

2800

EB-03

yellow

18000

3000

3000

2400

5400

4200

EB-04

grey

24000

4000

4000

3200

7200

5600

EB-05

red

30000

5000

5000

4000

9900

7000

EB-06

brown

36000

6000

6000

4800

10800

8400

EB-08

blue

48000

8000

8000

6400

14400

1120

EB-10

orange

60000

10000

10000

8000

18000

14000

EB-12

orange

72000

12000

12000

9600

21600

16800

EB-20

orange

120000

20000

20000

16000

36000

28000

EB-30

orange

180000

30000

30000

24000

54000

42000



 Cautions:

  • Failure to comply with this warning may result in serious load damage and death or injury.
  • Use only if trained.
  • Can fail if damaged, misused or overloaded.
  • Inspect sling for damage before each use.
  • Always protect sling webbing from sharp edges of load.
  • Do not attempt to use sling above rated lifting capacity.
  • Do not use sling if rated capacity tag is removed or unreadable.
  • Avoid acid, alkali and sunlight.
  • Do not tie knots in sling webbing as strength is greatly reduced.
  • Do not use sling if there are any signs of cut webbing,heat or chemical damage, excessive wear, or other defects.
  • Consult sling load chart for basket hitch capacity reduction due to sling angle.
  • Do not try to repair sling by yourself.
Detailed Images



Packaging & Shipping

 Packing and Shipping:

  • Packing: Carton case or pallet or other customized
  • Shipping: by ship or by air
  • Sample: Free but the freight
  • Deliver time: 1 container for 1 month
  • Load port: Shanghai or other ports in China



Company Information

Believe we are your right project partner as we own:

  1. Superior Quality & Reasonable Price
  2. Complete Project Management System
  3. Almost 10 years experience of OEM/ ODM service
  4. Large Production Capacity
  5. Professional Pre-Sales Service & Satisfaction After-Sales Service

Reliable Sling

  • Since 2011
  • Specializing in webbing slings, towing strap, ratchet tie down.
  • Consecutive sales increasement of 5 years
  • Passed the ISO9001:2008 and international certificate as CE, GS and TUV etc.
  • Provide OEM and ODM service to overseas customer
  • Export to more than 40 countries, mostly in European countries, America, Africa, Middle-east.
  • Our mission is to create high-quality, high-end products, allowing customers to use more convenient, more secure, more assured.

Our Service

Our service:

1. Any inquiries will be replied within 12 hours.

2. Professional manufacturer. Welcome to visit our homepage to more items:

3. OEM/ODM available:

  • Logo printed on the product;
  • Customized product details
  • Customized packages

4. Support your design whatever it is.

High quality guaranteed, reasonable & competitive price, fast lead time.

5. After-Sale Service:

  • All products will have been strictly quality checked before packing,
  • All products will have been well packed before shipping,
  • Any quality issues, high positive attitude to resolve it and warranty for customers' benefits!

6. Faster delivery:

Sample order in stock, and 3-7 days for mass production.

7. Shipping:

Strong cooperation with DHL,TNT, UPS, FEDEX, EMS, China Air Post.

Also you can choose your own shipping forwarder.

8. Payment:

Via: T/T, Western Union, PayPal & MoneyGram.

FAQ

1. How to order?

A: We are available via email, please feel free to send us your requests, and it will be nice of you to inform us detailed requests if you have. For example, size of goods, packing, and qty of each item.

2. Can I get a sample before placing order?

A: Surely you will! Reliable Sling offer samples for all our clients, sample is free, and freight to be covered by buyer.

3. What's your regular packing?

A: Products are usually packed in cartons and pallets, we would be more than glad to pack goods as instructed if you got special packing requests.

4. Delivery time

A: About 20days for qty less than 20GP.

B. Around 30days for 20GP, 40days for 40GP.

Welcome to look througth our website: www.reliablesling.com

You will find more items you are interested in it, please feel free to contact with us.
